Alpha Technologies AlphaCell GelCell Series - Manual (Page 26)

745-680-C0-002, Rev.B 26
6.0 Battery Parameters by Model Number, continued
Table 4, Battery Parameters, Legacy Models (threaded insert terminals)
Parameter
Model Number
215 GOLD HP 210GxL 190 GOLD HP 180GxL
Terminal Type Threaded Insert Threaded Insert Threaded Insert Threaded Insert
Bolt Size 1/4"-20 UNC Bolt 1/4"-20 UNC Bolt 1/4"-20 UNC Bolt 1/4"-20 UNC Bolt
Annual Retorque Inch-Pounds / N•m 110In-lb / 12.4N•m 110In-lb / 12.4N•m 110In-lb / 12.4N•m 110In-lb / 12.4N•m
Open Circuit Voltage 12.84 12.84 12.84 12.84
Average Float Voltage Range (volts/unit) 13.5 to 13.8 13.5 to 13.8 13.5 to 13.8 13.5 to 13.8
20-Hour Ampere Rate to 1.75 V/C 5.35 5.30 4.75 4.68
Typical Impedance @ 60Hz ohms 0.0050 0.0050 0.0050 0.0050
Typical Conductance 7Hz mohms 960 to 1400 960 to 1400 880 to 1320 880 to 1320
Typical 10 Sec. Voltage @ 100 amp 11.4 11.4 11.3 11.3
Parameter
Model Number
210GXL-HP/GXL 180GXL-HP/GXL 165GxL 160A
Terminal Type Lead Flag Lead Flag Lead Flag Lead Flag
Bolt Size 1/4"-20 1/4"-20 1/4"-20 1/4"-20
Annual Retorque Inch-Pounds / N•m 65 in-lb / 7.3N•m 65 in-lb / 7.3N•m 65 in-lb / 7.3N•m 65 in-lb / 7.3N•m
Open Circuit Voltage 12.84 12.84 12.84 12.84
Average Float Voltage Range (volts/unit) 13.5 to 13.8 13.5 to 13.8 13.5 to 13.8 13.5 to 13.8
20-Hour Ampere Rate to 1.75 V/C 5.30 4.68 4.30 4.40
Typical Impedance @ 60Hz ohms 0.0050 0.0050 0.0055 0.0040
Typical Conductance 7Hz mohms 960 to 1400 880 to 1320 800 to 1200 1040 to 1560
Typical 10 Sec. Voltage @ 100 amp 11.4 11.3 11.2 11.6
Table 5, Battery Parameters, Legacy Models, (Lead flag insert terminals)
