Alera Lighting S8 - Wall Mount User Manual
S8 wall mount, Technical installation data
Page 1/2 Rev. 09/10/13
Beams / S8 WM TID
s8 Wall Mount
Technical Installation Data
© 2013 Alera Lighting, a division of Hubbell Lighting, Inc. Alera Lighting reserves the right to change specifications without notice.
701 Millennium Blvd. Greenville, SC 29607 / Tel 864.678.1000 / Website www.aleralighting.com
sections
data chart
single Mounting (typical)
Connection Section
8"
row Mounting
End Section
Cross Section
6"
Nominal
Length
Weight
A
B
C
D
E
4'
18 lbs.
48"
43"
2 1/2"
5"
240"
8'
31 lbs.
96"
91"
2 1/2"
5"
480"
2-1/2"
2-1/2"
A
B
E
BottoM View
B
D
Single
C
Factory standard (typical row)
8 ft.
8 ft.
8 ft.
8 ft.
4 ft.
Feed
B
C
B
B
B
