Alera Lighting IQ - Wall Mount User Manual
Indiquest wall mount, Technical installation data
© 2010 Alera Lighting, a division of Hubbell Lighting, Inc. Because of continuing product improvement programs, Alera Lighting reserves the right to change specifications
without notice. 701 Millennium Blvd. Greenville, SC 29607 / Tel 864.678.1000 / Tech Support 864.678.1580 / Website www.aleralighting.com
Page 1/2 Rev. 01/15/10
CuRveS / IQ WM TID
IndIquest Wall Mount
Technical Installation Data
sectIons
BottoM VIeW
data chart
MountIng InforMatIon (LookIng aT WaLL “Through” FIxTure)
Connection Section
Cross Section
3 3/8"
5 1/2"
B
C
E
8'
G
2 Lamp T8
Perforated Bottom
5 9/16"
3 3/8"
2 3/4"
4'
A
C
Slots for attaching universal wall
mount bracket to the wall
B
D
F
H
H
F
D
F
H
Fixture brackets attach to universal
wall mount bracket
Nominal
Length
Approx. Weight
A*
B
C
D
E
F
G
H
1-lamp
4'
12 lbs.
—
2 23/32"
42 1/2"
24 1/16"
48 1/8"
27 1/16"
—
3"
8'
24 lbs.
96 1/16"
2 23/32"
90 5/8"
24 1/16"
—
27 1/16"
1 3/8"
3"
Note: Fixtures mounted in rows require two mounting locations per fixture.
End Section
7/8" KO for Power Feed
5 7/8"
