Air Squared E25H61N5.0 - Manual

Output 10 kW (nominal)
Expansion Ratio 5.26
Efficiency
80% (E25H61N5.0L)
70% (E25H61N5.0)
Max. Pressure 150 psia 10 bara
Displacement 155 cm 3 /Rev.
Max. Speed 3600 RPM
Max. Inlet Temp. 350°F 175°C
Avg. Sound Level 55 dB(A)
Working Fluid Refrigerant, Other Gases
Standard ORC Fluid R-134a, R-245fa
Direct Drive AC/DC Generator, Any Rotary Equipment
Wetted Materials Anodized Aluminum, Stainless Steel
Model Numbers
E25H61N5.0 (Oil-free)
E25H61N5.0L (Lubricated)
Air Squared
Manufacturing, Inc.
- 100% Oil-Free or Lubricated
- Low Sound Levels
- Balanced, Smooth, Rotary Motion
- High Efficiency
- Long Product Life
- Continuous Duty
- Minimal Pulsation
- Semi-Hermetic
Technical Overview
E25H61N5.0
40 Years of Scroll Technology
Product Features
Qualified OEM designers should consult Air Squared Manufacturing, Inc. for custom
configurations and application specific requirements. Contact [email protected].
The information presented in this material is based on technical data and test results of nominal
units. It is believed to be accurate and reliable. Air Squared, Inc. does not warrant, guarantee, or
assume liability in connection with this information.
Application conditions may adversely affect performance and product life. It is the responsibility
of the user to determine the suitability of the product for intended use.
10 kW Scroll Expander
- AC/DC Generator Available
Optional Configurations
