Air Squared P32H58N2.25 User Manual
Scroll compressor, 40 years of scroll technology, Air squared

US
World
Max. Pressure
20 psig
1.38 barg
Max. Flow
45 cfm
1275 lpm
Rated Power
3.35 hp
2.5 kW
Motor Type
Brushless DC or AC
Voltage
48V DC
Avg. Sound Level
65 dB(A)
Net Weight
55 lb
25 kg
Port Configuration
1” NPT
Ambient Temp.
0°F - 104°F
-20°C - 40°C
Model Number
P32H58N2.25
Scroll Compressor
Air Squared
Manufacturing, Inc.
-
100% Oil-Free
-
Low Sound Levels
-
Balanced, Smooth, Rotary Motion
-
High Efficiency
-
Long Product Life
-
Continuous Duty
-
Small Compact Design
-
Minimal Pulsation
-
Field Serviceable
Technical Overview
P32H58N2.25
40 Years of Scroll Technology
Product Features
-
BLDC or AC Motor
-
DC Controller Available For Purchase
-
Semi-Hermetic For Gases Other Than Air
Optional Configurations
Qualified OEM designers should consult Air Squared Manufacturing, Inc. for custom
configurations and application specific requirements. Contact [email protected].
The information presented in this material is based on technical data and test results of nominal
units. It is believed to be accurate and reliable. Air Squared, Inc. does not warrant, guarantee, or
assume liability in connection with this information.
Application conditions may adversely affect performance and product life. It is the responsibility
of the user to determine the suitability of the product for intended use.
