Air Squared V11H12N2.5 - Manual

US World
Max. Vacuum > 29 in Hg < 20 mbar
Max. Flow 0.42 scfm 12 slpm
Rated Power 0.054 hp 40 W
Motor Type BLDC
Voltage 12V-24V DC
Avg. Sound Level 25 dB(A)
Net Weight 2 lb 0.91 kg
Port Configuration 1/8” NPT
Max. Amb. Temp. 104°F 40°C
Model Number V11H12N2.5
Part Numbers 081210
Scroll Vacuum Pump
Air Squared
Manufacturing, Inc.
-
100% Oil-Free
-
Low Sound Levels
-
Balanced, Smooth, Rotary Motion
-
High Efficiency
- Long Product Life
-
Continuous Duty
-
Small Compact Design
-
Lightweight
-
Minimal Pulsation
- Field Serviceable
-
Available Semi-Hermetic For
Handling Gases Other Than Air
Technical Overview
Contact [email protected] for custom design information
or application specific requirements.
V11H12N2.5
40 Years of Scroll Technology
Product Features
