Air Squared P19H38N4.0 - Manual

US Europe
Max. Pressure 75 psig 5.17 barg
Max. Flow 15.2 cfm 430 lpm
Shaft Power 4.25 hp 3.17 kW
Motor Type AC (BLDC Optional)
Avg. Sound Level 65 dB(A)
Max. Amb. Temp. 104°F 40°C
Model Number P19H38N4.0
Part Numbers 040820
040820 Standard AC unit.
Scroll Compressor
Air Squared
Manufacturing, Inc.
- 100% Oil-Free
-
Low Sound Levels
-
Balanced, Smooth, Rotary Motion
-
High Efficiency
-
Long Product Life
- Continuous Duty
-
Small Compact Design
-
Lightweight
-
Minimal Pulsation
-
Field Serviceable
Technical Overview
Contact [email protected] for custom design information
or application specific requirements.
P19H38N4.0
40 Years of Scroll Technology
Product Features
Part Number Information
