Air Squared P16H30N3.25R - Manual

US World
Max. Pressure 20 psig 1.4 barg
Max. Flow 8.5 cfm 240 lpm
Rated Power 0.75 hp 0.56 kW
Motor Type Brushless DC or AC
Voltage 24V DC
Avg. Sound Level 45 dB(A)
Net Weight 14 lb 6.35 kg
Port Configuration 1/2” NPT
Ambient Temp. 0°F - 104°F -20°C - 40°C
Model Number P16H30N3.25R
Scroll Compressor
Air Squared
Manufacturing, Inc.
- 100% Oil-Free
- Low Sound Levels
- Balanced, Smooth, Rotary Motion
- High Efficiency
- Long Product Life
- Continuous Duty
- Small Compact Design
- Lightweight
- Minimal Pulsation
- Field Serviceable
Technical Overview
P16H30N3.25R
40 Years of Scroll Technology
Product Features
- Brushless DC or AC Motor
- Attached Cooling Fan
- DC Controller Available For Purchase
Optional Configurations
Qualified OEM designers should consult Air Squared Manufacturing, Inc. for custom
configurations and application specific requirements. Contact [email protected].
The information presented in this material is based on technical data and test results of nominal
units. It is believed to be accurate and reliable. Air Squared, Inc. does not warrant, guarantee, or
assume liability in connection with this information.
Application conditions may adversely affect performance and product life. It is the responsibility
of the user to determine the suitability of the product for intended use.
