11. Technical data
Article number TVCC50030 TVCC50530
Videosignal PAL
Resolution 650 TVL 650 TVL
Image sensor 1/3" Sony Interline Super HAD II Dual Scan CCD
DSP SONY Effio
Picture elements (total) 1028(H) x 596 (V)
Picture elements (effective) 976(H) x 582 (V)
Signal-to-noise ratio 50 dB
Minimum light sensitivity (day) 0.005 Lux @ F1.0, 30 IRE
Minimum light sensitivity
(night) 0.001 Lux @ F1.0, 30 IRE (B/W Mode)
0 Lux @ F1.0, 30 IRE (IR On)
Automatic day/night switching Removable IR cut filter (ICR), Color / B/W
Lens CS/C-Mount, manual or DC controlled
Synchronization Internal
DSS (Frame Integration) 0 ~ 128x
Automatic Gain Control (AGC) 62.8 dB (max.), 32 Level
Backlight compensation (BLC) WDR, Wide Dynamic Range
White balance ATW / AWB / PTL
Gamma 0.45 ~ 1, 9 Level
Wide Dynamic Range Max. 54 dB
DNR (Digital Noise Reduction) 2D+3D DNR
Iris level adjustment Auto
Mirroring Horizontal, Vertical, Horizontal/Vertical, Off
Control elements OSD, QIS/Normal
Protection class IP34
Video signal Composite; 1.0V p-p, 75 Ohm
Operating temperature -10°C ~ +50°C
Humidity 0~85%, not condensing
Nominal supply voltage 12 VDC / 24 VAC 110~240 VAC
Power consumption 4.5 W 4.5 W
Dimensions (WxHxD) 68,91 x 58,5 x 121,3 mm
Weight 420 g
68.91mm 110.5mm
121.3mm
58
.5
mm
