3
2.2. Installation of the hinge element
2.2.1. Please route the cables through the
hinge element.
2.2.2. Put the hinge element into the bracket
with routed cables and fix the element
from downside using the fixing screw.
2.3. Installation of the base part
2.3.1. For the next steps please remove the
upper part from the base part of the
housing.
2.3.2. Remove the screw nut from the cable
gland on the base part.
2.3.3. Route the cables through screw nut and
cable gland.
2.3.4. Connect the cables on the inside of the
base part of the housing.
2.3.5. Fix the screw nut back on the cable
gland.
