ABUS TV8493-TV8495 User Manual

Page 11

2.5. Adjustment of camera position

2.5.1. Please remove the screws from the

camera tray on the inside of the base
partl.

2.5.2. Put the camera on the camera tray.
2.5.3. Fix the camera on the tray using a

screw.

2.5.4. Use the long holes to adjust the camera

position.

2.5.5. Fix the camera tray using the fixing

screws.

2.6. Installation of the upper part

2.6.1. Put the upper part back the to the base

part.

2.6.2. Screw back the ground cable to the

upper part on the marked position.

2.6.3. Screw back the ground cable to the

base part on the marked position.

2.7. Installation of the sunshield

2.7.1. Put the sunshield on top of the upper

part of the housing in alignment with the
back part of the housing.

2.7.2.

Fix the sunshield using the fixing
screws.
