6
Hinweis: The outdoor housing TV8493 got the
VdS approval number V108002.
3. Technical data
• 230 VAC connection
• Integrated heating
• Protection class IP67 (TV8493, TV8494)
Protection class IP54 (TV8495)
• VdS environmental class IV
• Inside routed cables
• Operation temperature: -20 to +50°C
• Weight: 2,56 kg without bracket
3,39 kg with bracket
• Max. load (for VdS concept installations):
0.4 kg
• Max. dimensions (base-/upper part):
L/W/H (mm): 410/154/123
• Max. dimension (bracket):
L/W/H (mm): 270/110/160
• Max. dimension (camera):
L/W/H (mm): 215/80/64
• TV8493: 230VAC connection, 230VAC
heating, VdS certification
• TV8494: 230VAC connection, 230VAC
heating, pre-installed 12VDC / 800 mA
Netzteil
• TV8495: 230 VAC connection, pre-installed
3,5 A PSU, 12 VDC heating, 12 VDC fan
TV8493 TV8494 TV8495
certification VdS - -
