32
English
OSD DISPLAY
Specifies whether or not the camera name and the time are displayed in the live view.
SCREEN POSITION
You can raise or lower the X (horizontal) and Y (vertical) values to move the displayed image on the
screen (X: -4 to 3; Y: -10 to 10).
BORDER COLOR
Changes the colour of the border on the screen.
The following colours are available: BLACK, GREY1, GREY2, WHITE and OFF.
8.3 Setting the sequence time
AUTOSEQ TIME SETUP VER 1.20
CH 1-4: 01S
CH 1: 01S
CH 2: 01S
CH 3: 01S
CH 4: 01S
↑↓ Select + - Adjust EXIT
Fig. 7: Sequence time settings
You can define the dwell time for each channel here (“OFF”–99).
If a camera is disconnected, this channel is automatically skipped in the sequencing.
8.4 Channel settings
CHANNEL SETUP VER 1.20
CH: 1
TITLE: CH01
BRIGHTNESS: -20
CONTRAST: +20
SATURATION: 0
HUE: 0
↑↓ Select + - Adjust EXIT
Fig. 8: Channel settings
