22
English
6.2 Cleaning
Wipe the product with a clean, dry cloth. If the device is very dirty, you can moisten the cloth with
lukewarm water.
Ensure that no liquids can get into the device.
Do not use any chemical cleaners, since they could damage the housing surface or the
screen (discolorations).
7. Disposal
Important: The EU Directive 2002/96/EC regulates the proper return, treatment and
recycling of used electronic devices. This symbol means that in the interest of
environmental protection the device must be disposed of separately from household or
industrial waste at the end of its service life in accordance with applicable local legal
guidelines. Disposing of used devices can be done at official recycling centers in your
country. Obey local regulations when disposing of material. Further details on returns
(also for non-European countries) can be obtained at your local authority. Separate
collection and recycling saves natural resources and ensures that all the provisions for
protecting health and environment are observed when recycling the product.
8. Technical Data
Model number TVCC34010
Image sensor 1/3" DIS
Camera type Day/night outdoor camera
Resolution 600 TVL
Pixels (effective) 720 (H) x 480 (V)
Lens 3.6 mm, fixed lens
Horizontal angle of view 68.4°
Day/night switch Electromechanical IR-cut filter
Minimum illumination (colour) 0.1 lux
Minimum illumination (IR) 0 lux
Noise reduction > 52 dB
Electronic shutter control 1/25 ~ 1/15,000 sec.
Backlight compensation Yes
Video system PAL / NTSC
IR LEDs 12
IR range 10 m
Connections Video signal (BNC), power supply (DC)
Power supply 12 V DC
Power consumption Max. 5 W
Operating temperature -20 °C – 50 °C
Humidity Max. 90%
Protection class IP 66
Dimensions (Hx

) 89.6 mm x 59.1 mm
Weight 400 g
