P C / 1 0 4 P e r i p h e r a l M o d u l e P C M - 3 6 6 0 R e v . B
PCM-3660 Rev.B Quick Installation Guide 1-4
Specification
Hardware

Form Factor PC/104

I/O address 200, 220, 240, 260, 280, 2A0, 2C0, 300,
320, 340, 380 or 3A0

Interrupt levels IRQ3, 4, 5, 9, 10, 11, or 15

Boot ROM address C0000, C8000, D0C00 or D8000H

Data bus 8-bit or 16-bit, auto-sensing

Connectors 16-bit PC/104 stack through connector
RJ-45 connector for 10BASE-T, 16-pin
insulation displacement connector for AUI

Dimension 3.5” x 3.8” (90mm x 96 mm )
Software

Driver Support -Lantasti 4.x/5.xdriver
-NDIS 2.x driver
-Packet driver
-SCO UNIX driver
-Netware ODI driver
-NDIS 3.0 miniport driver for Windows NT
31, Windows NT 35 and Windows 95
-OS2driver
