Technical Data
© Gardner Denver Deutschland GmbH 7 / 32 610.444430.40.000
3 Technical Data
3.1 Mechanical data
Weight
Type Weight
approx.
[kg]
approx.
[lbs]
2BV3151 9 19.8
Higher weights are possible with special
models.
Minimum distances for heat dissipation
Type Minimum distance from
fan guard to adjacent surface
[mm] [inches]
2BV3151 20 0.787
Noise level
Measuring-surface sound-pressure level
according to EN ISO 3744 measured at a
distance of 1 m [3.28 ft] with moderate
throtteling (8 kPa abs. [1.16 psia]) and lines
connected.
Type 1-m measuring-surface sound
pressure level L [dB (A)
at 50 Hz: at 60 Hz:
2BV3151 70 70
Operating speed
See rating plate.
NOTICE
Exceeding of the operating speed will
negatively affect the operating behavior of the
pump-motor unit:
 higher
noise emissions
 stronger vibrations
 shorter grease consumption time
 reduced bearing change interval
To prevent damage due to excessively high
speeds, it may be necessary to request the
limit speed
(inquire with the Service
Department).
Tightening torques
The values specified here for tightening
torques apply unless other values are
indicated.
Tightening torques
for screw connections
(pipe-connections)
Thread [Nm]
± 10 %
[ft lbs]
± 10 %
G⅛ 4.5 3.32
G⅜ 16 11.8
Tightening torques
for electrical connections
(terminal board-connections)
Thread [Nm]
± 10 %
[ft lbs]
± 10 %
M4 1.0 0.738
M5 2.2 1.62
These values for electrical connections applies
to all terminal board connections with the
exception of modular terminal blocks.)
Tightening torques
for electrical connections
(modular terminal blocks)
Thread [Nm]
± 10 %
[ft lbs]
± 10 %
M3 0.6 0.443
(These values for electrical connections apply
to all modular terminal blocks.)
3.2 Electrical
data
See drive motor rating plate.
3.3 Operating
conditions
Temperatures
Temperature of pumped gases/vapors:
max. +110 °C max. +230 °F
At higher fluid temperatures, measures must
be taken on the system to prevent burns, e.g.
mount separating safety device (cover).
In addition, we also recommend one of the
following measures at temperatures > 80 °C
[> 176 °F]:
 Increasing the operating-liquid flow rate by
up to twice the rated liquid flow rate (cooling
circuit)
 Use of a series capacitor
