OM-06628 SFV SERIES X‐PROOF PUMPS
PAGE E - 9 MAINTENANCE AND REPAIR
SFV4B-X Pump Model Assembly
Parts List
1 PUMP CASING
. -ANSI SEE NOTE BELOW 1
. -DIN SEE NOTE BELOW 1
2 IMPELLER SEE NOTE BELOW 1
3 IMPELLER WASHER 31514-017 17000 1
4 SOCKET HD CAPSCREW MBD1025 17000 1
5 . PIPE PLUG P02 17000 1
6 O‐RING 25152-273 --- 1
7 MOTOR ASSY CONSULT FACTORY
8 LOCK WASHER MJ12 17000 6
9 HEX HD CAPSCREW MB1245 17000 4
10 TERM HOUSING ASSY NOT AVAILABLE
11 LOCK WASHER NOT AVAILABLE
12 HEX NUT NOT AVAILABLE
13 HEX HD CAPSCREW MB1230 17000 2
14 LIFTING BAIL ASSY 44713-048 17040 1
15 SEAL PLATE 38272-535 10000 1
16 O‐RING 25152-377 --- 1
17 FLAT HD CAPSCREW MF0516 17000 1
18 SHAFT SLEEVE O‐RING 25154-022 --- 1
19 SHAFT SLEEVE 31441-030 1706H 1
20 SEAL ASSY 25285-856 --- 1
21 SPRING RETAINER 31161-042 17000 1
22 IMP ADJ SHIM SET 37J 17090 1
23 INFINITY DECAL 38811-435 --- 1
24 NAME PLATE NOT AVAILABLE 1
25 DRIVE SCREW NOT AVAILABLE 4
NOT SHOWN:
STAGGERWING DECAL 38811-434 --- 1
G‐R DECAL GR-03 --- 1
OPTIONAL:
ANSI SLIDE RAIL VERSION
GUIDE SHOE KIT 48156-559 --- 1
-GUIDE SHOE SEAL 31513-054 19020 1
SLIDE RAIL KIT 48156-024 --- 1
ALIGNMENT KIT 48786-551 --- 1
BASEPLATE KIT
-SHORT
48156-603 --- 1
-LONG 48156-604 --- 1
LIFTING CABLE KIT
-36'
48151-502 --- 1
-50' 48151-504 --- 1
DIN SLIDE RAIL VERSION
GUIDE SHOE KIT 48156-560 --- 1
-GUIDE SHOE SEAL 31513-054 19020 1
SLIDE RAIL KIT CONSULT FACTORY 1
ALIGNMENT KIT 48786-552 --- 1
BASEPLATE KIT
-SHORT
CONSULT FACTORY 1
-LONG CONSULT FACTORY 1
LIFTING CABLE KIT
-36' 48151-502 --- 1
-50' 48151-504 --- 1
LIQUID LEVEL DEVICES:
DIAPHRAGM TYPE GRP48-03 --- 1
GRP48-06 --- 1
FLOAT TYPE 27471-180 --- 1
120V LIQUID LEVEL
CONTROL RELAY 27521-321 --- 1
. INCLUDED W/ANSI REPAIR PUMP CASING ASSY 46472-914 --- 1
. INCLUDED W/DIN REPAIR PUMP CASING ASSY 46472-921 --- 1
INDICATES PARTS RECOMMENDED FOR STOCK
NOTE: WHEN ORDERING A REPLACEMENT IMPELLER, PROVIDE THE FACTORY WITH THE PUMP MODEL, S/N AND IMPELLER
DIAMETER (FROM NAMEPLATE)
