SVS 100 Introduction

SVS 100 Features

Four NTSC or PAL video inputs

2 S-video or composite video inputs

— 2 rear panel, 4-pin mini-DIN

connectors (Input 1 and Input 2) accept luminance (Y) and chrominance (C)
input. Alternately, 2 rear panel BNC connectors accept composite video
input. The video inputs can be specified through a menu system, as either
Auto, Video, or S-video. Auto will automatically select the active input. If
S-video and composite video are both input, the SVS 100 will automatically
select the S-video input.

2 composite video only inputs

— 2 rear panel BNC connectors (Input 3 and

Input 4) accept composite video input.

Any inputs must either be all NTSC or all PAL, they cannot be both.

Four NTSC or PAL buffered output loops

2 S-video or composite buffered output loops

— Input 1 and Input 2 each

output a buffered loop of the selected video input on either 4-pin mini-DIN
connectors (S-video) or BNC connectors (composite).

2 composite video only buffered output loops

— Input 3 and Input 4 each

output a buffered loop of the composite video input on BNC connectors.

Three NTSC or PAL video outputs

2 composite video outputs

— Switched outputs on rear panel BNC

connectors

1 S-video output

— Switched output on rear panel 4-pin mini-DIN connector

Four balanced/unbalanced stereo audio inputs

— Four rear panel captive screw

terminals accept audio inputs. Each input’s level can be individually preset.

Pre-amp output

for powered speakers is provided on a 3.5 mm, 5-pole captive

screw terminal.

Seamless switching

— Noise and other video glitches are eliminated by a user-

selectable assortment of cut, wipe, dissolve, and fade effects.

Genlock connection

— A black burst external sync signal can be input and daisy-

chained via rear panel BNC connectors.

Picture controls

— Color, tint, brightness, contrast, and top and bottom blanking

can be adjusted for each input to correct for differences between sources.

Audio breakaway

— Audio and video can be switched separately by using

RS-232 control. This feature can be set through Extron’s Simple Instruction
Set™ (SIS™).

RS-232/RS-422 control

— A computer or other RS-232/RS-422 control device can be

used to control the SVS 100 switcher with Extron’s Simple Instruction Set™
(SIS™) or the Windows-based control program.

Memory

— 128 picture configurations can be stored in memory.

Versatile mounting options

— The SVS 100 can be rack mounted, or it can be

mounted under a desk or table, or against a wall or the side of a desk.
Mounting brackets are included.

1-3
