Transmitter rear panel features – Extron Electronics MTP 15HD A Series User Guide Rev. C User Manual
Page 13
J
Delay (skew adjustment) control (SEQ model only) — This control delays the
selected Red, Green, or Blue video signal by up to 62 nanoseconds. The delay is
applied in incremental, 2-nanosecond steps. Rotate the control counterclockwise to
reduce the delay or clockwise to increase the delay.
NOTES:
•
The control turns smoothly; it does not have mechanical steps or high and low
limit stops.
•
Watch the displayed image to observe the steps of delay.
•
The selected Red, Green, or Blue LED (
I
) flashes to indicate that the control
has reached the minimum (counterclockwise rotation) or maximum (clockwise
rotation) limit.
K
DIP switches (RL receivers only) — A 5-pole DIP switch is used to configure the
features of the MTP receivers.
•
•
Horizontal sync (H Sync +) switch — Set this switch On (up) for positive
horizontal sync or Off (down) for negative sync.
•
•
Vertical sync (V Sync +) switch — Set this switch On (up) for positive vertical
sync or Off (down) for negative sync.
NOTE: Most devices use negative sync for H Sync and V Sync.
•
•
S-Video switch — This switch is used to set which pins of the 15-pin HD
connector S-video is output on.
•
•
Set this switch On (up) to output chroma on pin 3 and luma on pin 2.
•
•
Set this switch Off (down) to output chroma on pin 1 and luma on pin 2.
•
•
End Unit switch — Set this switch On (up) if either of the following is true:
•
•
The receiver being configured is the only receiver connected to the transmitter.
•
•
The receiver being configured is the last receiver in a daisy-chained system.
Set the End Unit switch Off (down) on the receiver being configured if there are one
or more receivers connected to the Buffered Output RJ-45 connector (see
C
on
page
).
MTP 15HD A Series • Installation and Operation
8
