Extron • Model 8 PLUS & Model 10 PLUS Switchers • User’s Manual Page 2-4
_ The S-Video output from the SVHS VCR would most likely
require a user supplied S-Video to BNC adapter to connect to
the Model 8 PLUS or Model 10 PLUS switcher. The Extron
Part Number for an adapter of this type is 26-353-01.
Composite video outputs and audio outputs from Laser Disc
Players and VCRs will most likely require RCA to BNC
adapters. An adapter of this type can generally be purchased
at your local electronics store.
Model 8/10 PLUS Operation and Configuration
