17

2002 - INLINE, INC. MSV0502 OPERATION MANUAL - v1.0 4/26/02
COMMAND DESCRIPTION
[VOLLooxxx] Sets left channel volume level for a specific output.
•
Where
o oo = 01 - 02 for output
o xxx = -550 - 090
o Note: 090 equals max (9 db gain), 000 equals factory
default (unity gain), -550 equals minimum (-55db)
[VOLRoox] Sets right channel volume level for a specific output.
•
Where
o oo = 01 - 02 for output
o x = + (plus sign) to increment output volume
o x = - (minus sign)to decrement output volume
o x = @ to return output volume to factory default
o x = ? to request current volume level
[VOLRooxxx] Sets right channel volume level for a specific output.
•
Where
o oo = 01 - 02 for output
o xxx = -550 - 090
o Note: 090 equals max (9 db gain), 000 equals factory
default (unity gain), -550 equals minimum (-55db)
[VOLx] Sets volume level for all outputs.
•
Where
o x = + (plus sign) to increment output volume
o x = - (minus sign) to decrement output volume
o x = @ to return output volume to factory default
o x = ? to request current volume level
[VOLRMPoox] Starts volume ramp of a specific output.
•
Where
o oo = 01 - 02 for output
o x = + (plus sign) for volume ramp up
o x = - (minus sign) for volume ramp down
[VOLSTOP] Stop volume ramp function.
[VINiix] Sets input volume level for a specific input.
•
Where
o ii = 01 - 05 for input
o x = + (plus sign) to increment input volume
o x = - (minus sign) to decrement input volume
o x = @ to return input volume to factory default
o x = ? to request current volume level
[VINiixxx] Sets input volume level for a specific input.
•
Where
o oo = 01 - 05 for input
o xxx = -640 - 000
o Note: 000 equals max (factory default), -640 equals
minimum
