Specifi cations
Video
Gain ................................................ Unity
Resolution....................................... 8 or 10 bits, automatic
Operation standards ..................... 143 Mb/s (4f
sc
NTSC)
177 Mb/s (4f
sc
PAL)
270 Mb/s (4:2:2 component video)
360 Mb/s (4:2:2 widescreen component
video), autoselected
Equalization and re-clocking ....... Automatic for up to 30 dB of cable loss
Video input
Number/signal type ..................... 1 SMPTE-259M serial digital component
video
Connectors ..................................... 1 BNC female
Nominal level ................................ 0.8 Vp-p
Minimum/maximum levels ........ 0.5 V to 1 Vp-p with no offset
Impedance ..................................... 75 ohms
Return loss ..................................... <-15 dB @ 5 to 270 MHz
Maximum DC offset ..................... 5 V (AC coupled)
Video output
Number/signal type ..................... 4 reclocked SMPTE-259M serial digital
component video
Connectors ..................................... 4 BNC female
Nominal level ................................ 0.8 Vp-p
Minimum/maximum levels ........ 0.5 V to 1.0 Vp-p
Impedance ..................................... 75 ohms
Return loss ..................................... <-25 dB @ 5 MHz
DC offset ........................................ ±5 mV maximum with input at 0 offset
Sync
Standards ........................................ 4f
sc
NTSC, 4f
sc
PAL, SMPTE-259M
General
External power supply ................. 100 VAC to 240 VAC, 50/60 Hz, external,
autoswitchable; to 12 VDC, 1 A, regulated
Power input requirements ........... 12 VDC, 0.4 A (max.)
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Rack mount .................................... Yes, with optional 1U rack shelf,
part #60-190-01, or 60-604-01;
or the VersaTools
® rack shelf, part
#60-190-20 or 60-604-20
Enclosure type .............................. Metal
Enclosure dimensions .................. 1.7" H x 4.3" W x 3.0" D
(1U high, quarter rack wide)
4.2 cm H x 11.0 cm W x 7.6 cm D
(Depth excludes connectors and knobs.)
Product weight .............................. 0.5 lbs (0.2 kg)
Shipping weight ........................... 2 lbs (1 kg)
Vibration ........................................ ISTA 1A in carton
(International Safe Transit Association)
Listings............................................ UL, CUL
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................... 30,000 hours
Warranty ........................................ 3 years parts and labor
N All nominal levels are at ±10%.
N Specifi cations are subject to change without notice.
