IN1124/28/30 Transmission System • Introduction
Introduction, cont’d
IN1124/28/30 Transmission System • Introduction
About the TP Receiver
The Extron IN1130 TP receiver receives the transmission of one
of transmitter’s proprietary video and audio signal over a TP
cable. The receiver then decodes the received signal and buffers
and distributes two identical video outputs on female 15-pin
HD connectors. The receiver buffers and distributes two
identical mono audio outputs on 3.5 mm mini jacks.
The receiver has a sharpness control that fine tunes the
compensation to optimize the video outputs for various cable
lengths.
Features
IN1124 TP transmitter/distribution amplifier
Frequency range — Supports 15 kHz to 130 kHz horizontal
frequency.
Computer video input — Accepts computer analog video on a
15-pin HD female connector. With an adapter cable, the
transmitter can accept Macintosh, 13W3 video, RGBHV,
RGBS, RGsB, component video, S-video, or single source
composite video input.
Buffered local monitor output — Allows you to view the
displayed image on a local monitor.
Audio input — Accepts stereo PC audio on a 3.5 mm stereo
mini jack. The transmitter sums the left and right audio
channels into two identical mono channels.
RJ-45 connectors — Allows connection to up to four Extron
IN1130 TP RGB video receivers.
Mounting — Can be rack mounted with Extron’s 1U rack shelf
(part #IN9080).
1-4 1-5
IN1128 TP transmitter/distribution amplifier
Frequency range — Supports 15 kHz to 130 kHz horizontal
frequency.
Computer video input — Accepts computer analog video on a
15-pin HD female connector. With an adapter cable, the
transmitter can accept Macintosh, 13W3 video, RGBHV,
RGBS, RGsB, component video, S-video, or single source
composite video input.
Buffered local monitor output — Allows you to view the
displayed image on a local monitor.
Audio input — Accepts stereo PC audio on a 3.5 mm stereo
mini jack. The transmitter sums the left and right audio
channels into two identical mono channels.
RJ-45 connectors — Allows connection to up to eight Extron
IN1130 TP RGB video receivers.
Mounting — Can be rack mounted with Extron’s 1U rack shelf
(part #IN9080).
IN1130 TP receiver
The IN1130 TP receiver has the following features:
Video output — Provides two RGBHV, RGBS, or RGsB outputs
on 15-pin HD connectors. With an optional SY-VGA
cable, the receiver can output component video, S-video,
or composite video.
Audio output — Outputs mono audio on both the tip (left) and
the ring (right) of two 3.5 mm stereo mini jacks.
RJ-45 connector — Allows attachment to an Extron IN1124 or
IN1128 TP transmitter/DA.
Mounting — Can be mounted to virtually any flat surface with
Extron’s optional mounting brackets (part #IN9089).
