©2001 - INLINE, Inc. IN3260 Operation Manual - V 1.0 10/31/01
11
Specifications
IN3260
Installation Distribution Amplifier
Input
Connector Type
(1) 15-pin HD male (female connector available upon request)
RGB Video Signal Analog, 1.5 Vp-p max.
Input Terminations 75 ohms
Sync Signals TTL compatible
Compatible Formats RGBHV / RGBS / RGsB / RGBHVS
Horizontal Sync Range 15 to 130 KHz
Vertical Sync Range 30 to 120 Hz
Stereo Audio Input 3.5mm Stereo Mini Female, Unbalanced Audio
Output
Buffered Local Monitor
15-pin HD female (male connector available upon request)
Main Output Six (6) BNC female
Output Format Same as Input - RGBHV / RGBS / RGsB / RGBHVS
Video Gain 1.0 / 1.2 / 1.4
Local Audio Output 3.5mm Stereo Mini Female, Unbalanced Audio
Main Audio Output 5-Pin Captive Screw Terminal, Unbalanced (Default) or Balanced
General
Bandwidth
400 MHz @ -3 dB
Internal Jumpers Local Monitor Output Gain, Main Output Gain,
Audio Output Balanced / Unbalanced,
Monitor Emulation Auto / Always Grounded
Power
Power Supply
9 VDC, 500 mA
Dimensions
Size (including J-Box)
4.5” x 6.4” x 2.6” / 11.4cm x 16.3cm x 6.6cm
Weight Shipping: 4lbs. / 2 kg. Product: 2lbs. / 0.9 kg.
Regulatory Compliance
Safety
UL 1950, CAN/CSA-22.2 No. 950, Third Edition
EMI
FCC class A; CE: EN55022 (1987), EN50081-1 (1991),
EN50082-1 (1992 and 1994), EN60950-92
Parts Included
(1) IN3260 Installation Distribution Amplifier
(1) IN9204 External Power Supply
(1) IN9334 Allen Wrench
(1) IN9161 3-Gang Junction Box - 2.5” Deep
(1) IN9154 ¾” EMT Conduit Coupler, Set-Screw Type
