7
© 2001 - INLINE, INC. IN3552R / IN3562R OPERATION MANUAL - REV. 1.1 11/16/01
SPECIFICATIONS
IN3552R
RGBHV Switcher
IN3562R
VGA Switcher
Inputs
Connector type 5 BNC Female 15 Pin HD Male
Number of Inputs 2 Inputs 2 Inputs
Maximum Signal
Components per Input
5 6
Signal Compatibility RGBHV, RGBS, RGsB, RsGsBs,
Monochrome with Sync, Composite Video,
Y/C, Component Video, Audio
RGBS, RGsB, RsGsBs,
RGBHV, RGBHVS
Monochrome with Sync, Composite Video,
Y/C, Component Video, Audio
Output
Connector type 5 BNC Female 15 Pin HD Female
Bandwidth
650 MHz
.7Vp-p input signal @ - 3dB
500 MHz
.7Vp-p input signal @ - 3dB
Isolation 60 dB @ 50 MHz 55 dB @ 75 MHz 50 dB @ 100 MHz
Switching Time 2.5 mSec Typical
Power
Voltage 120/230 VAC; 60/50 Hz - Set at Factory
Consumption 10 Watts
Dimensions
Size Height: 1.65" / 4.2cm Width: 8.5" / 21.6cm Depth: 6" / 15.2cm
Product Weight 2.2 lbs. / 1.0 Kg
Shipping Weight 4 lbs. / 2 Kg
Regulatory Approval
Safety
UL 1950, 3
rd
Ed.; CE: EN60950-92;
CAN/CSA-22.2 No. 950 3
rd
Ed.
EMI / ESD
FCC class A; CE: EN50081-1,
EN55022, EN50082-1
