2

IN3552R / IN3562R OPERATION MANUAL - REV. 1.1 11/16/01

©2001 - INLINE, INC.

INSTALLATION

This section offers step-by-step instructions for installing IN3552R / IN3562R switchers. A detailed
application drawing showing all equipment connections is shown on the next page.

1. Connect both sources to the IN3552R / IN3562R input connectors.


IN3552R: An interface may be required for each computer video signal source in order to split
off a signal for each local monitor, bring all signals into the RGBHV format, and amplify the
signal to compensate for long input/output cable runs.

IN3562R: A 1x2 distribution amplifier (IN3262 / IN3262D) may be required at each computer
in order to split off a signal for each the computer’s local monitor, provide monitor emulation and
amplify the signal to compensate for long input/output cable runs. If the computer video outputs
are being connected directly to the switcher inputs, it may be necessary to set the IN3562R input
termination switches to emulate a VGA or MAC monitor. Information on these dip switches is
silk screened on the bottom of the unit and can also be found on page 5.


2. Connect the IN3552R / IN3562R output to the display device.
3. Apply AC power to the unit.


IN3552R: Use IN7000-5, IN7100-5, IN7200-5, IN7300-5 Series - 5 Conductor Cables,

available in a variety of lengths from 6’ to 250’, terminated with male BNC connectors.

IN3562R with VGA, MAC, SUN, SGI, 4&5-BNC computer graphics cards, monitors and
data displays:
Use the input / output adapter cables as indicated in the chart below.

IN3562R INPUT / OUTPUT ADAPTER AND EXTENSION CABLES


VGA MAC SUN (13W3 - RGBS) SGI (13W3 RGsB) 5-BNC (RGBHV/RGBS/RGsB )

Input Cables 6’ Long

IN8006

IN9140

IN9142

IN9148

IN9048

12’ Long IN8012

IN9046

25’ Long

IN8025

IN9144

IN9146

IN9150

IN9046-L25

50' to 250'

IN8000 Series

IN9046-Lxx

Output Cables 3' Long

N/A

IN9141

IN9143

IN9149

6’ Long IN8006

IN9047

12’ Long IN8012

IN9045

25’ Long

IN8025

IN9145

IN9147

IN9156

IN9045-L25

50' to 250'

IN8000

Series

IN9045-Lxx


It is very important that all input / output connections be made utilizing high resolution
coaxial cables. Proper cable selection is critical to overall system performance,
especially when working with high frequency signals and/or long cable runs. The
following cables are recommended for use with the IN3552R / IN3562R switchers.
