YSI 9300 Photometer User Manual
Page 18
15
3
The instrument will be set automatically. After a few seconds the following
display will appear:
Place SAMPLE TUBE in the test chamber, then press [OK].
4
The instrument will take the reading and display the result as follows, for
example:
The following symbols indicate the result is out of test range:
Result is higher than range: >>
Result is lower than range: <<
5
The ‘options menu' offers the choice to:
‘Choose a Test’ - return to the menu of test programs and select another
test
‘Read’
- read further sample tubes of the currently selected test
‘Blank’
- re-blank the instrument
‘Follow-On’
- carry out a continuation test if available.
C hlorine-Free / 5
P h o t 007
Insert S am ple
Bla nk - Choos e a Te s t - Tim e
OK
Chlorine-Free / 5
Phot 007
1.00
mg/l Cl
2
Choose a Test
Read Blank Follow-On
