Bell & Gossett P58725B Series 1535C Close Coupled Centrifugal Pump - Manual

INSTALLER: PLEASE LEAVE THIS MANUAL FOR THE OWNER’S USE.
Series 1535C Close Coupled
Centrifugal Pump
DESCRIPTION
The Carrier Series 1535C is a close-coupled pump designed
for heavy duty operation. The 1535C provides ease of main-
tenance, is made of rugged material and is offered in a wide
range of standard sizes.
OPERATIONAL LIMITS
Series 1535C pumps are designed to pump liquids compatible
with their bronze fitted construction at working pressures up to
175 psi and a maximum temperature of 225°F.
Do not exceed these values.
Pump Construction:
Bronze Fitted
Standard Mechanical Seal:
BUNA – PH Limitations 7-9;
Temperature Range – -20° to +225°F
Your Series 1535C pump should have this warning label affixed
to the pump near the conduit box cover. If this warning is
missing or illegible, contact your local Carrier Representative
for a replacement.
SAFETY
INSTRUCTION
This safety alert symbol will be used in this manual and on
the pump instructions decal to draw attention to safety
related instructions. When used, the safety alert symbol
means ATTENTION! BECOME ALERT! YOUR SAFETY IS
INVOLVED! FAILURE TO FOLLOW THE INSTRUCTIONS
MAY RESULT IN A SAFETY HAZARD.
W A R N I N G
BEFORE INSTALLING,
USING OR SERVICING
THIS PRODUCT, READ
THE WARNING NOTES
AND INSTRUCTIONS
IN INSTRUCTION
MANUAL. FAILURE TO
DO SO MAY RESULT
IN SERIOUS INJURY
OR PROPERTY DAMAGE.
INSTRUCTION MANUAL
P58725B
