Operation of Writer / WriterWL
Units
Fixed units
Pressure Bar mBar mWs PSI Pa kPa MPa mmHg ATM
Temperature °C °K °F
Length/height m inch foot yard
Sample specification of user-defined units on the configuration screen
The units set in the main window are used in all further dialog boxes.
Read Configuration
Initialization of the connected data logger is commenced by clicking this button.
Stop Record
Clicking this stops any recording already started.
Write Configuration
By clicking this, the configuration settings are written out to the connected device.
The status of the recording can be checked in the status bar by going into online-mode immediately
after Write Configuration.
Example: Recording stopped >> recording ready >> recording started (provided the start-event has
occurred).
Cancel
Communication with the connected device is broken off.
Exit
The program is exited
Warning!
Don’t ever forget to initiate the recording by clicking on "Write Configuration"!
