2 technical specifications, Communication modules – Xylem 205547 Profibus Communication Modules User Manual
Page 7
2.2 Technical Specifications
Profibus Communications unit
Mounting
On backside of display unit
Dimensions
51 x 82 mm ( H x W)
Connectors
Two 5-position plugable screw terminal
Temperature
-20 to +60 °C
LEDs
LEDs for “Rx”, “Tx”, “3V3”, “
µc” and “prof”
Power consumption
Approx. 0.75 VA
Com. type
RS 485
Baud rate
Up to 12MB
ID offset
(profibus address)
1-125
Protocol
Modbus RTU
The corresponding GSD File allows 244Bytes reading and 244Bytes writing to
the converter.
2. Profibus Communication Modules
Communication Modules
