2.5 Confi guration Remarks
The connected units on the Profi bus COM module have unique assigned IDs
built as follows:
• COM module confi guration/setup is executed from the “Display Setup/
Profi bus COM module” menu (see below).
• The “Profi bus COM module” option in the display menu automatically
appears, when a communication module is connected to the display.
• Profi bus ID is the address for the Profi bus
Display setup
Language
Set Clock
Factory settings
Display SW version
Bluetooth
Graphs
Profibus COM modul
Setup overview screen
Back Select OK
Profibus COM modul
Profibus ID
Profibus Status
Back Select OK
Profibus ID
Set ID
----
Back Select OK
Profibus Status
Ok / Fail
Back Select OK
Profi bus COM Module
Profi bus ID
FW Version
Counters
