Profibus
“Offset Read
Default”
Type Register name Explanations Device measure-
ment Location
LowB HighB # Status Com. Modul Modbus adr.
LowB HighB #
mA Bus Converter
(Device 1)
162 163 B16
System Error bit
1-16
See mA Bus Converter Documentation 1001
164 165 B16 Alarm Error 1 See mA Bus Converter Documentation 1002
166 167 B16 Alarm Error 2 See mA Bus Converter Documentation 1003
168 169 B16 Digital input Bit 1-16 See mA Bus Converter Documentation 200
170 171
F32
{Low}
mA 1 Scaled See mA Bus Converter Documentation 300
172 173
F32
{High}
- - 301
174 175
F32
{Low}
mA 2 Scaled See mA Bus Converter Documentation 304
176 177
F32
{High}
- - 305
LowB HighB #
mA Bus Converter
(Device 2)
178 179 B16
System Error bit
1-16
See mA Bus Converter Documentation 1001
180 181 B16 Alarm Error 1 See mA Bus Converter Documentation 1002
182 183 B16 Alarm Error 2 See mA Bus Converter Documentation 1003
184 185 B16 Digital input Bit 1-16 See mA Bus Converter Documentation 200
186 187
F32
{Low}
mA 1 Scaled See mA Bus Converter Documentation 300
188 189
F32
{High}
- - 301
190 191
F32
{Low}
mA 2 Scaled See mA Bus Converter Documentation 304
192 193
F32
{High}
- - 305
Profibus
“Offset Read
Default”
Type Register name Explanations Device measure-
ment Location
LowB HighB # Status Com. Modul Modbus adr.
4.3 mA Bus Converter Register List
Communication Modules
