4.1 MagFlux Register List
Profibus
“Offset Read
Default” Register name Explanations Device measure-
ment Location
LowB HighB Type # MagFlux1 (Device 1)
10 11 B16
System Error bit
1-16
See MagFlux Modbus Documentation 1001
12 13 B16 Alarm / Sensor Error See MagFlux Modbus Documentation 1002
14 15
F32
{Low}
Flow now Flow now [m3/sek] 600
16 17
F32
{High}
- - 601
18 19 U64{1}
Total Forward Flow1
- LS word
Forward Total [mm3] 604
20 21 U64{2}
Total Forward
Flow1 - 2
- 605
22 23 U64{3}
Total Forward
Flow1 - 3
- 606
24 25 U64{4}
Total Forward Flow1
- MS word
- 607
26 27 U64{1}
Total Reverse Flow1
- LS word
Reverse Total [mm3] 610
28 29 U64{2}
Total Reverse
Flow1 - 2
- 611
30 31 U64{3}
Total Reverse
Flow1 - 3
- 612
32 33 U64{4}
Total Reverse Flow1
- MS word
- 613
MagFlux2 (Device 2)
34 35 B16
System Error bit
1-16
See MagFlux Modbus Documentation 1001
36 37 B16 Alarm / Sensor Error See MagFlux Modbus Documentation 1002
38 39
F32
{Low}
Flow now Flow now [m3/sek] 600
40 41
F32
{High}
- - 601
42 43 U64{1}
Total Forward Flow1
- LS word
Forward Total [mm3] 604
44 45 U64{2}
Total Forward
Flow1 - 2
- 605
46 47 U64{3}
Total Forward
Flow1 - 3
- 606
