17
Dimensions
Ultrasonic sensor 7005
Pressure transmitter 7062
Specifications
Ultrasonic sensor 7005-1013 7005-1023
Measuring range: 3 m (10 m) 30 cm or 100 cm
Frequency: 30 kHz 100 kHz
Spreading: 3 o
Temperature
compensation: built-in
Temperature: -0 - +60 o C
Dimensions: ø103 x 94 mm
Materials: PP Green / POM Black
Cable: Screened oil resistant PVC, length 1 m
Can be extended to:100 m 50 m
Housing: IP 68, water proof, withstands immersion, max. 1 bar
Pressure Transmitter 7062-1413 7062-1423 7062-1433
Measuring ranges: 0-30 cm 0-1 m 0-3 m
Function: -wire, 4-0mA
Accuracy: ±0,5%
Temperature: -10 - +60 o C
Dimensions: ø60 x 13 mm
Materials: House: PP
Diaphragm: Gold-plated ceramic, socket in steel (AISI 316L)
Cable: x0,5mm , length 1 m, can be extended.
Mounting: 1" thread. Mounted on pipe.
Housing: IP 68, water proof, max. 0,5- bar
Flow Converter 713
Measuring ranges: 0 - 30 cm, 0 - 1 m, 0 - 3 m
Supply:
0-40, 110-10 or 4V AC, ca. 10 VA
Temperature: -0 - +60 o C
Input signal: From ultrasonic sensor or pressure transmitter, 4-0 mA
Accuracy: ±1% (min. ±1 mm)
Outputs: plug 6-17 Relay 1 to 4, max. 50V, 4A ohmic, max. 100 VA
Inductive load 100VA. Can be chosen as alarm,
counter, Flow>0 or sampler outputs.
plug 18-0 Relay 5 (as 1-4) or Pulse (optocoupler) max. 36 V, 50 mA
one shot, 100msec. - 10 sec. programmable
plug 1- Analogue: 0-0 / 4-0 mA max. 500W galvanic isolation
Facultativeformula: Q =k.h x ; Q=Flow, h=heigth, k=factor, x=exponent (ISO 1438)
or point linearization
Indication: x4 characters LCD display for reading and programming
Dimensions: 185 x 40 x 115mm (HxWxD)
CE: EN50081-1, EN5008-1
Housing: IP 65
Flow Converter 713
Order numbers
Part no: Specifications:
201450 713U-1111 Ultrasonic measuring system, range 0-30 cm
201455 713U-1121 Ultrasonic measuring system, range 0-1 m
201460 713U-1131 Ultrasonic measuring system, range 0-3 m
202600 713-1104 Flow Converter without sensor, 4-20 mA input
202650 713P-1114 Hydrostatic measuring system, range 0-30 cm
202655 713P-1124 Hydrostatic measuring system, range 0-1 m
202660 713P-1134 Hydrostatic measuring system, range 0-3 m
Accessories Flow Converter 713:
200105 Panel Mounting kit
200115 Local mounting set with rain roof
200205 Universal bracket
Accessories Pressure Transmitter 7062:
202922 Connection box for cable for pressure transmitter 7062
Accessories Ultrasonic Sensor 7005:
200205 Universalbracket
200220 Bracket for ultrasonic sensor 7005
200590 Connection box for cable for ultrasonic sensor 7005
690010 Cable for ultrasonic sensor 7005
Sensors:
200570 Ultrasonic sensor 7005-1013, 30 kHz
200575 Ultrasonic sensor 7005-1023, 100 kHz
202942 Pressure Transmitter 7062-1413, 0-30 cm
202943 Pressure Transmitter 7062-1423, 0-1 m
202944 Pressure Transmitter 7062-1433, 0-3 m
Accessories for mounting:
Universal bracket
Bracket for ultrasonic sensor 7005
