13
Sample key
SAMPLE
If one or several of the digital outputs are configured for
controlling a sampler, pressing this key will give following
indications:
F16 Number of samples
Press once for:
/0/95 04:39:1
NUMBER OF SAMPLES: 3445
This display indicates how many samples have been
taken since last reset or system start up. Press ENTER
for reset, see menu F19.
F17 Number of samples today
Press twice for:
TODAY 00:00 - 17:
NUMBER OF SAMPLES: 45
This display indicates how many samples have been
taken within 4 hours (00:00:00 - now).
F18 Number of samples 24 HR
Press three times for:
4 HR : 30/06/95
NUMBER OF SAMPLES: 11
This menu indicates how many samples were taken
yesterday. Value and date for the previous 4 hours are
indicated.
F19 Reset value
Reset is possible from the menues F5, F6, F7, F9, F10,
F11. By using the enter key and the following menu will
appear:
RESET type
YES: Enter NO: Menu
Menu key
MENU
This key allows access to the menus with reading and
programming of the readings and functions of the flow
converter. In menus with various options the choices will
be seen on top of one another, the top choice being the
current value. By pressing one arrow (up or down) the
choice varies. A choice is confirmed by pressing ENTER.
Non confirmed choices will flash on the display, where
as a current/confirmed choice stands firm.
0.1 Level
Press once for:
LEVEL= 543. I= 1.3 mA
D1=0 D=0 D3=1 D4=1 D5=0
Here the measured level (LEVEL), the value for the
analog output (I) is indicated. The digital outputs are indi-
cated as D1-D5. 0 indicates non activated output, where
as 1 indicates activated outputs. Outputs chosen to "not
in use" are not shown.
0.2 Language
Press twice for:
LANGUAGE ENGLISH
DANSK
By pressing arrows the languages can be altered. When
changing to a new language the display will be clear for
a few seconds.
0.3 Enter access code
Press three times for:
KEY IN ACCESS CODE
USE ARROW KEYS 0000
This menu shows, when an access code has been cho-
sen (four figures) in the configuring menus. Double ar-
rows changes the first two digits, single arrows changes
the last two digits. Press ENTER for confirmation of
choice of access key. When the access code is correctly
keyed in access to the configuring menus will be given
for 5 min. since last key pressed.
0.4 Access denied
What happens when the wrong access code is keyed in:
ACCESS DENIED
It will not be possible to make changes in the set up. Re-
turn to the previous chosen functional menu by pressing
the ESC-key once.
