WISKI-Converter
The design of this module is very similar to that of the Text-Converter. It is also used for creation of a
text-file which can be used for further processing or for display.
Under "Options – Configuration - General" there are two selectable formats.
ZRXP-Format:
If the data is converted into this format, it can be displayed and processed with
the WISKI - TimeSeriesViewer from the firm Kisters (30-day demo version
available
here ).
CSV-Format:
This format is a widely-used general semicolon-separated format with the
following pattern:
Date;Time;P1-P2 [bar];P1 [bar];P2 [bar];TOB1 [°C];TOB2 [°C]
29.11.2002;13:15:05;0,0001;0,9628;0,9626;22,9336;23,3125
...
Operating Manual for Logger DCX 4.0 KELLER AG Page 27
