Save if delta Channel > Val1
Recording only takes place if the measured value of the channel where event-driven recording is
scheduled is greater by Val1 than the last recorded value. After Write Configuration a reference
value will be recorded.
= measured Value
= Recording
= Reference measuring
}
Val1
}
Val1
}
Val1
Recording if delta Ch > Val1
t
Ch
Start recording if Channel > Val1
Recording is started as soon as the measured value of the channel where event-driven recording is
scheduled is greater than Val1.
= measured Value
= Recording
Start Recording if Ch > Val1
Val1
t
Ch
Start recording if Channel < Val1
Recording is started as soon as the measured value of the channel where event-driven recording is
scheduled is less than Val1.
= measured Value
= Recording
Start Recording if Ch < Val1
Val1
t
Ch
