Operation
CR 4200
24
ba76121e01
09/2012
Connect the thermoreactor with a printer and download the test
report to the printer (see section 5.5.2).
Leave the temperature test program with g.
The test report in the thermoreactor is erased in any case at the end.
5.5.2
Downloading the test report to an external printer/PC
To transmit the temperature test report to a printer or PC, a printer
cable or PC cable is required (see chapter 9 A
You can record the test report with the aid of a so-called terminal
program on the PC side.
Generally, a terminal program serves to establish a connection to a
meter at a data interface and to communicate with the meter via a
console on the display. A terminal program usually offers the possibility
to save the contents of the console in a text file or print it. If the terminal
program is connected to the thermoreactor, it can receive the
temperature test report and display it on the console.
Terminal programs are available by different manufacturers for
different operating systems. The "HyperTerminal" terminal program is
included in Windows (versions 95 to XP). It is in the program menu
under Accessories.
More detailed information can be taken from the user information of the
terminal program.
Sample report
Downloading the test
report
Precondition:
The temperature test is finished and PRINT is displayed (see page 5-
23).
Note
When connecting the PC or printer cable observe the cable poling.
Data transmission is possible with the correct poling only.
CR 4200 V.X.XX
Tref = 148 C
1: Tblock = 147.5 C
2: Tblock = 147.6 C
3: Tblock = 147.7 C
. . .
. . .
1 Disconnect the external temperature probe from the
thermoreactor.
