YSI Incorporated 8 650 MDS
Figure 2. 650 interfaced to a 6-series sonde with user-supplied GPS.
Figure 3. 650 interfaced to PC for data transfer or software upgrade.
You will need:
•
650
•
6115 GPS cable
•
User-supplied GPS unit
with DE-9 cable
•
YSI 6-series sonde with
integral or field cable
650
YSI 6-series sonde
Integral or field cable
User-supplied GPS unit
with DE-9 cable
6115 GPS cable
You will need:
•
650
•
YSI 655174
PC interface
cable
•
PC with
active serial
port
650
PC Serial port
(DE-9)
655174 PC Interface
Cable
