Operation Lab 960
46 ba75557e05 11/2009
4.7.3 Downloading stored measurement datasets
4.7.4 Downloading calibration data
4.7.5 RS232 interface
2 If necessary, set an interval with <
▲><▼>.
3 Close the setting with .
The download to the interface takes place at the specified
interval.
1 Open the storage menu with .
2 If necessary, scroll with until Sto Prt is displayed.
3 Press to download the calibration data to the interface.
1 Open the storage menu with .
2 If necessary, scroll with until CAL Prt is displayed.
3 Press to download the calibration data to the interface.
1 Connect the interface to the PC or printer via the cable Z390
(PC) or Z393 (ext. printer).
2 If necessary, disconnect a connected USB cable from the
meter.
3 Set up the following transmission data on the PC/printer:
– Baud rate: selectable from 1200, 2400, 4800, 9600,
– Handshake: RTS/CTS + Xon/Xoff
PC only:
– Parity: none
– Data bits: 8
– Stop bits: 1
