14.1.1 Automatic connection to the programming device
Auto Connecting
Enabled
!Only valid for programming device!
Auto connecting enabled: that after plug in of the
programming device, it changes automatically to the inverter menu. During this auto
connection the programming device is looking for a valid address and “SCAN
CONNECTION” is shown on the display (see chapter 10.2).
Auto connecting will be stored after leaving the submenu Configuration.
Auto connecting disabled: there is no automatic connecting with the pump (choose
the address)
Press Î on the controller to change to
14.1.2 Software Version of the programming device
Software:
Software: VOGREM-004
In the second line of the display, there is shown the
version of the software of the programming device
and also the date of programming of this software.
To leave the submenu press the Î key for 3 sec.!
14.2 Submenu address
Submenu
Address
To enter this menu you have to press the Ð key, to
leave the menu, press the Î key longer than 3 sec.
14.2.1 Change of pump address
Address Change
00--> 00 *
Addresses from 01 to 04 and also 00 can be set in
this parameter. To change the address it is
not necessary to cut the interface connection to other HYDROVARS.
On the left side there is shown the address of the HYDROVAR, which you want to
speak (select the address by using the buttons Ï or Ð). On the right side, then you
can give the HYDROVAR a new address also with the buttons Ï and Ð
. You only can
give an address, which is not used in the pump group!
To change between left and right side, press button Í or Î. The star shows the
actual used side.
To save the new selected address press both buttons (Í and Î) together for 2 sec. If
it was successfully you will see the same address on both sides.
To leave the submenu press the Î key for 3 sec.!
