General for working with the external programming device:
With Í and Î you can select the different parameters in the menu.
To enter a submenu, press the Ð button. To leave the submenu, you have to press
the buttons Í or Î for longer than 3 sec.
With Ï or Ð you can change the parameters.
Each change in the settings is saved after leaving this parameter with the buttons
Í
or Î.
When you have changed a parameter and you leave it, the LCD shows you the
following message
SAVE
PARAMETER
for about 2 sec.
10
Connecting the external programming device to the HYDROVAR
After connection of the HYDROVAR – head to the power supply and plug in of the
external programming device, there can be shown two different messages:
1. If the AUTOCONNECTION (14.1.1) is disabled (standard) you reach:
Address 01
Lost
This message is shown, when the Remote Control is
new connected
At this time the Hydrovar searches for an available address
If address 01 is available, the display changes to
Address 01
Detected
The actual pump-address is shown
Statusinformations by systems with activated Multicontroller:
P1: Masterpump
P2: Slavepump
P3: Slavepump
P4: Slavepump
P.: Follownumber is not useful
Hold: pump stops through the pressure transmitter
Run: pump runs
Stop: pump stops through the leadpump
Disabled: pump stops through the stopbutton or the terminal block
Error: pump stops through an error
Ð
Follow pump stopped
Ï
Regulator from the follow pump is release
Pump don’t work at the follow pump
