SSV Product Line
Numbering System for 33 – 92SV
The various versions of the SSV line are identified by a product code number on the pump label. This number is also
the catalog number for the pump. The meaning of each digit in the product code number is shown below.
Note: Not all combinations are possible. Consult your G&L distributor.
Example Product Code
33 SV B G 1 2 R 6 T A H
Pump Options (optional – to be listed in sequential order)
H = Horizontal mounting D = High Pressure Pump (40 Bar) ①
Q= 1.0 Service Factor Version (AQ) T = Alternative Motor Frame
Seal Options:
Motor Enclosure:
D = ODP T = TEFC
X = Explosion Proof P = TEFC Premium Effy
Motor Voltage:
1 = 115/230 2 = 230 3 = 230/460 4 = 460
5 = 575 6 = 208-230/460 7 = 200 8 = 190/380
HP Rating:
G = 2 HP M = 15 HP S = 50 HP
H = 3 HP N = 20 HP T = 60 HP
J = 5 HP P = 25 HP U = 75 HP
K = 7½ HP Q = 30 HP
L = 10 HP R = 40 HP
Motor Hertz/Speed/Phase:
1 = 60 Hz/3500/1 2 = 60 Hz/3500/3 3 = 60 Hz/1750/1 4 = 60 Hz/1750/3
5 = 50 Hz/2900/1 6 = 50 Hz/2900/3 7 = 50 Hz/1450/1 8 = 50 Hz/1450/3
9 = 60 Hz/Variable/3
Number of Reduced Impellers (can be 0, 1, 2) *
Total Bowls/Stages:
A = 1 E = 5 J = 9
B = 2 F = 6 K = 10
C = 3 G = 7
D = 4 H = 8
Flange Orientation:
B = Cast Iron/316 stainless steel, in-line ANSI flange
D = 316 stainless steel, in-line ANSI flange
Product Line:
Stainless Vertical Vertical
Nominal Flow:
33 = 150 GPM 66 = 350 GPM
46 = 225 GPM 92 = 450 GPM
Code No. Rotary Stationary Elastomers
A
Carbon
Viton
Mechanical Seal
B
Silicon Carbide
EPR
C
Silicon Carbide
Viton
D EPR
Cartridge Seal
L Silicon Carbide Carbon Viton
P Graphite Filled Silicon Carbide EPR
– Metal parts on all seals are 316SS.
– Silicon carbide is graphite filled.
* NOTE: Indicates number of reduced diameter
impellers in the total staging.
(2 would indicate 2 reduced diameter impellers)
① Alternative motor frame will be next larger frame size than
what is standard.
