Xylem GLSSV2 SSV Series Vertical Multi-Stage Pumps D1 - Manual (Page 17)

15
3500 RPM, 60Hz
HP Phase Enclosure
Nameplate NEMA Goulds
FLA SFA
LRA
S.F. Efficiency
Insulation
Voltage Frame PN ② ¹ Class
1
ODP 115/230 56C V04721 7/3.6-3.5 7.9/4.06-3.95 21 1.15 66 B
TEFC 115/230 56C V04722 7/3.6-3.5 7.9/4.06-3.95 21 1.15 66 B
½ ODP 230/460 56C V04741 2.1/2-1 2.52/2.4-1.2 6 1.25 68 B
3 TEFC 230/460 56C V04742 2.1/2-1 2.52/2.4-1.2 6 1.25 68 B
X-Proof 230/460 56C V04743 2.1/2-1 NA 6 1 68 B
1
ODP 115/230 56C V05721 9.4/4.9-4.7 10.8/5.63-5.4 26 1.25 72 B
TEFC 115/230 56C V05722 9.6/5-4.8 11.4/5.94-5.7 28 1.25 66 B
¾ ODP 230/460 56C V05741 2.7-2.6/1.3 3.15-3/1.5 7.6 1.25 74 B
3
TEFC 230/460 56C V05742 2.7-2.6/1.3 3.15-3/1.5 7.6 1.25 74 B
X-Proof 230/460 56C V05743 2.7-2.6/1.4 NA 7.6 1 74 B
Prem. Eff. TEFC 230/460 56C V05742PE 2.0/1.0 2.3/1.15 7 1.15 82.5 B
1
ODP 115/230 56C V06721 15/7.9-7.5 15.8/8.217.9 48 1.25 65 B
TEFC 115/230 56C V06722 11/5.5 13.5/6.75 38.5 1.25 66 B
1
ODP 230/460 56C V06741 3.7-3.6/1.8 3.99-3.8/1.9 11 1.25 75.5 B
3
TEFC 230/460 56C V06742 3.7-3.6/1.8 3.99-3.8/1.9 11 1.25 75.5 B
X-Proof 230/460 56C V06743 3.7-3.6/1.9 NA 11 1 75.5 B
Prem. Eff. TEFC 230/460 56C V06742PE 2.8/1.4 3.12/1.56 12.1 1.25 84.5 B
1
ODP 115/230 56C V07721 12.8/7-6.4 14.5/7.9-7.3 76 1.15 80 B
TEFC 115/230 56C V07722 16/8.4-8 18/10-9 50 1.15 70 B
ODP 230/460 56C V07741 4.9-4.6/2.3 5.3-5.1/2.54 18.4 1.15 80 B
1½ TEFC 230/460 56C V07742 4.9-4.6/2.3 5.3-5.1/2.54 18.4 1.15 80 B
3 X-Proof 230/460 56C V07743 5-4.6/2.3 NA 16 1 75.5 B
Prem. Eff. ODP 230/460 56C V07741PE 4.2/2.1 4.6/2.3 16 1.15 85.5 B
Prem. Eff. TEFC 230/460 56C V07742PE 4.0/2.0 4.5/2.25 20.1 1.15 85.5 B
1 ODP 115/230 56C V08721 24/12.6-12 28.6/14.3 80 1.15 70 B
TEFC 115/230 56C V08722 23/12-11.5 24.2/12.1 78 1.15 74 B
ODP 208-230/460 56C V08741 6.2-5.8/2.9 7.2-6.52/3.26 22 1.15 80 B
2 TEFC 208-230/460 56C V08742 6.2-5.8/2.9 7.2-6.52/3.26 22 1.15 80 B
3 X-Proof 208-230/460 56C V08743 5.4/2.7 N/A 17.5 1 78.5 B
Prem. Eff. ODP 208-230/460 56C V08741PE 5.5-5/2.5 6.2-5.6/2.8 22 1.15 86.5 B
Prem. Eff. TEFC 208-230/460 56C V08742PE 5/4.75-2.5 6.4-5.8/2.9 30 1.15 86.5 B
1
ODP 230 56C V09721 14.4/13 16.4-14.8 108 1.15 82.5 B
TEFC 115/230 56C V09722 27/13.5 33/18/16.5 11.4 1.15 80 F
ODP 208-230/460 56C V09741 8.5-8/4 10-9/4.5 30.9 1.15 80 F
3 TEFC 208-230/460 56C V09742 8.1-7.6/3.8 9.5-8.6/4.3 32.9 1.15 82.5 F
3 X-Proof 208-230/460 56C V09743 7.8-7.4/3.7 NA 27 1 82.5 F
Prem. Eff. ODP 208-230/460 56C V09741PE 7.4/3.7 9.1-8.2/4.1 29 1.15 87.5 F
Prem. Eff. TEFC 208-230/460 184TC V09742PE 6.8/3.4 8.5-7.7/3.8 32 1.15 88.5 F
1
ODP 208-230 184TC V10721A 24-23 30.1-27.2 125 1.15 75 F
TEFC 208-230 184TC V10722A 23.5 41.8-37.8 110 1.15 84 F
ODP 208-230/460 184TC V10741A 13.1-11.5/5.7 15.3-13.8/6.9 48 1.15 84 F
5 TEFC 208-230/460 184TC V10742A 13.2-12/6 15-13.6/6.8 47 1.15 85.5 F
3 X-Proof 230/460 184TC V10743A 13.2-12/6 NA 47 1 85.5 F
Prem. Eff. ODP 208-230/460 184TC V10741APE 11.2/5.6 14.4-13/6.5 55 1.15 90.2 B
Prem. Eff. TEFC 208-230/460 184TC V10742APE 11.2/5.7 14.4-13/6.5 55 1.15 90.2 F
Motor Data
