59
Technical Data – Pump Hydraulics / Motor Sizing
46SV 2900 RPM
# of Impellers / Maximum HP Motor HP for use Shutoff TDH Shutoff TDH Casing / Sleeve Stages requiring Pump Flange
# reduced Draw with 1.15 SF (Feet) (Bar) Pressure rating Thrust Balancing Rating
Diameter Motor (@ 50 Hz) (Standard Assy.) Piston
10 45.9 256 7.6
10/1 44.1 251 7.5
10/2 42.4 246 7.3
9 41.3 40 231 6.9
9/1 39.6 225 6.7
9/2 37.8 220 6.6
8 36.7 205 6.1
8/1 35.0 200 6.0
8/2 33.3
30
194 5.8
7 32.0 180 5.4
7/1 30.3 174 5.2
7/2 28.6 169 5.0
6 27.5
25
154 4.6
6/1 25.7 148 4.4
6/2 24.0 143 4.3 25 Bar (362 PSI) Class 125 / 150
5 22.9 128 3.8 1
5/1 21.2
20
123 3.7
5/2 19.4 117 3.5
4 18.4 103 3.1
4/1 16.6 97 2.9
4/2 14.9
15
92 2.7
3 13.8 77 2.3
3/1 12.1 72 2.1
3/2 10.3
10
66 2.0
2 9.1 51 1.5
2/1 7.5 7.5 46 1.4
2/2 5.6 41 1.2
1 4.6 5 26 0.8
1/1 3.8 23 0.7
1 Pump assembly may be modified for 40 bar (580 psi) application – contact factory.
