38
Dimensions and Weights
3SV Series 2900 RPM
Stage
Frame (1-Phase) Frame (3-Phase) L2 D1 (max.) Weights (lb)
ODP TEFC ODP TEFC HP L1 ODP TEFC L3 L4 L5 M1 (ref.) M2 (ref.) ODP TEFC Liquid End ODP TEFC
2
1½
15.31
11.19 12.06
15.31 15.31 33
43 51
3 56C 56C 16.81 16.81 16.81 5.75 5.56 7.19 7.19 35
4 2 18.31 11.56 13.44 18.31 18.31 37 51 56
5 184TC 184TC 3 19.81 12.69 19.81 19.81 40 75 85
6 22.81
13.94 15.44
15.69 22.81 22.81
6.88 6.63 8.50 8.50
44
8 213TC 184TC 5 24.25 17.19 24.25 24.25 45 101 124
9 25.38 20.19 25.38 25.38 47
11
213TC 213TC 215TC 7½
28.38
15.50
21.69 28.38 28.38
8.06 8.77 10.25
62
130 151
12 29.88
15.56
24.63 29.38
10.19
64
14
215TC 254TC 10
32.88
16.56
32.88
9.25 10.31
68
128 250
16 35.88 35.88 72
L2
L1 +
L2
L1
D1
FILL
3/8 BSP
DRAIN
3/8 BSP
1.77
(45)
3.45
(90)
M1
REF
M2
REF
L1
L1 +
L2
L2
FILL
3/8 BSP
DRAIN
3/8 BSP
5.91
(150)
1.77
(45)
3.45
(90)
L3
Ø 5.00 B.C.
(127)
Ø .71 (18)
8 HOLES
6.50
(165)
2" CLASS 300
7.87
(200)
1.38
(35)
3.15
(80)
1½ NPT
L4 + L2
L4
14.88
(378)
10.28
(261) 1.38 (35)
2.35 (59.7)
11.81
(300)
L5 + L2
L5
3.15 (80)
SVC FLANGE
SVA
SVB
SVD
VICTAULIC
2" NPT
All dimensions are in inches (mm).
8.47 (215)
5.12 (130) Ш .51 (13)
