CP-Series Submersible Motors Installation, Operation and Maintenance Manual 3
CAUTION
NOTICE
Overview and Product Description
II. Overview
This manual gives important information concerning the installation, use and maintenance of the motors.
The contents of this manual refer to the standard product, as presented in the sales documentation. Any
special versions will be supplied with supplementary instruction sheets. Please refer to the sales contract for
the features of variants and special versions. Always specify the exact type of motor and code when request-
ing our Sales and Service Department for technical information or spare parts. For any instructions, situations
and events not covered in this manual or in the sales documentation, please contact the nearest Technical
Assistance Center.
Read this manual carefully before installing and using the product.
Improper use may cause personal injury and/or damage to property, and invalidate the war-
ranty.
III. Product Description
The CentriPro CP-Series comprises 6”, 8”, 10” and 12” submersible rewindable motors with stator and rotor
immersed in a bath of lubricating liquid consisting of demineralised water and anti-freeze. 6" and 8" motors
are equipped with NEMA-standard flange and shaft dimensions. For 10" and 12" motor sizes please consult
this product's technical bulletin for mounting dimensional details.
All the metal parts in contact with the water are either made from stainless steel or cast iron.
Each motor includes a Kingsbury pivoted-shoe thrust bearing and winding wire. The winding wire will be
either standard or special high temperature type.
