e-SV Product Line

Numbering System for 1 – 22SV Pump & Motor Combination

The various versions of the e-SV line are identified by a product code number on the pump label. This number is also

the catalog number for the pump. The meaning of each digit in the product code number is shown below.

Note: Not all combinations are possible.
Example Product Code

2 SV 2 2 F A 2 F 5 1 A H

Special Configurations (1 or 2 Characters)

A = Jacketed Seal only

J = Horizontal mount + Passivation

B = Jacketed Seal + Passivation

K = Horizontal mount + Low NPSH

C = Jacketed Seal + Low NPSH

L = Horizontal mount + High Pressure

E = Electro-Polished

M = i-Alert (standard for 10 HP units and greater)

F = Destaged - 1 stage

N = Low NPSH only

G = Destaged - 2 stage

P = Passivation only

H = Horizontal mount only

Z = High Press (250/300# pump body)

Seal Material

0 = Carb-SilCar-Viton

4 = SilCar-SilCar-EPR

1 = Carb-SilCar-AFLAS (HighTemp)

6 = Carb-SilCar-EPR

2 = SilCar-SilCar-Viton

Motor Enclosure

1 = ODP

7 = Prem-XP

2 = TEFC

8 = Prem-WD

3 = X-Proof

9 = Marine

4 = WD - Tropical

A = Chem

5 = Prem-ODP

B = Prem-Chem

6 = Prem-TEFC

Voltage

A = 115-230

H = 190/380

R = 220

B = 230

J = 115/208-230

S = 415

C = 230-460

K = 208

T = 220/380 WYE

D = 460

L = 208-230

U = 380-660 WYE

E = 575

M = 190/380/415

V = 208-230/460 WYE

F = 208-230/460

N = 380

G = 200

P = 110/220

Pole-Hz-Phase

1 = 2-50-1

5 = 4-50-1

2 = 2-50-3

6 = 4-50-3

3 = 2-60-1

7 = 4-60-1

4 = 2-60-3

8 = 4-60-3

HP Rating

A = 0.50

H = 7.5

B = 0.75

J = 10

C = 1.00

K = 15

D = 1.50

L = 20

E = 2

M = 25

F = 3

N = 30

G = 5

P = 40

Configuration OPTION

C = Clamp-316

F = Round-304 (SVB)

R = (SVC) 12Suct-12Disch

G = CI-304

W = (SVC) 12Suct-03Disch

N = Round-316 (SVD)

X = (SVC) 12Suct-06Disch

P = Victaulic-316

Y = (SVC) 12Suct-09Disch

T = Oval-304 (SVA)

Total Number of Impeller Stages (may be 1 or 2 characters)
Product Line:

SV – Stainless Vertical

Nominal Flow:

1 = 5 GPM

10 = 53 GPM

3 = 16 GPM

15 = 80 GPM

5 = 26 GPM

22 = 116 GPM

Suction

discharge

location

Top / Bottom
