Watchman “b” design (full motor) pump parts list – Bell & Gossett DN0156F HS Vented Condensate Units Watchman Series SCC User Manual
Page 7
7
ITEM
NUMBER
PART
NUMBER
DESCRIPTION
REQUIRED
NUMBER
1
Motor
1
/
3
hp. 1ph, 3500 rpm
1
DM0005
2
Seal Holder
1
DP1966
3
Seal*
1
–
4
Impeller
1
DP0321
5
Head Gasket*
1
DG0092
6
Pump Case with Wearing Ring
1
DP1665
7
Capscrew
4
DJ0083
8
Wear Ring
1
DP0482
9
Pipe Plug
1
/
4
"
1
P39040
10
Water Slinger
1
DP0848
Seal Kit including Mechanical
*
Seal, Head Gasket & Case to
1
180013
Receiver Gasket
Complete Pump and
Motor Assembly
1
180001
Or
der Replacement Parts by Description and Part No.
Specify Serial No. shown on nameplate.
1
10
7
3
4
8
6
9
5
2
W
ATCHMAN “B” DESIGN (FULL MOTOR) PUMP PARTS LIST
