13
Note: Jumpers not indicated are for test purposes only.
5
JPB
BMC Enabled
Pins 1~2 (enable)
6
JPG1
VGA Enable
Pins 1~2 (enable)
7
JPL1
GLAN1 Enable
Pins 1 (enable)
8
JPRST1
BMC/PHY Enable
Pins 1~2 (enable)
9
JWD
Watch Dog
Pins 1~2 (reset)
No.
Jumper
Description
Default Setting
